FEATURED 2026  Diamond C  FMAX216  40' x 102" - 13530

2026 Diamond C FMAX312 40' x 102"

TANDEM - DUAL WHEEL GOOSENECK TRAILER

The FMAX216 tandem dual wheel gooseneck trailer offers a 30K – 40K GVWR and is up to 1,800 pounds lighter than the competition. Designed for those who need to get the job done, this gooseneck flatbed trailer delivers unparalleled performance and efficiency. The FMAX216 is also available in the Pacesetter version, which includes options for Hydraulic Dovetail and Max Ramps loading, providing enhanced functionality and convenience. Do work with the FMAX216 and experience the difference.

NEW FLEETNECK 2.0 FEATURES

• New, Lighter Neck: The Fleetneck 2.0 neck web is stronger and lighter with the new 10-gauge Grade 80 material resulting in a 65-pound weight reduction.
• New Spare Mount Location: The new spare tire mount location with the easy-to-handle winch that raises and lowers the spare is now located under the trailer deck, guaranteeing it is out of your way until you need it.
• Grade 100 Beams: Grade 100 main frame beams with a 10-gauge thickness have doubled the yield strength of the Fleetneck 1.0.
• Chain Tray/Winch Mount: Storing your chains is easy with the standard chain tray with a winch mount combination and has the option to add a bolt-on winch box.

Features May Include:

Max Ramps

•  44″ wide ramps for MAX versatility. 50 ksi steel ramp frames x 4 frames per ramp for MAX strength. HD Spring loaded for easy lifting. For safe, stable loading.

12' Hydraulic Dovetail

• 12′ long with easy to climb, 12.5 degree approach angle. Includes Blackwood rubber-infused runners for traction, automatic latch for easy operation, and wireless remote control.

XDR Ramps

• These 24″ x 60″ spring-assisted extreme duty knee ramps are perfect for loading concentrated machines such as backhoes and excavators where space between the ramps is a necessity for knuckle height clearance.

Straight Deck

• The Straight Deck tail configuration includes 3″ channel 96″ Rear Slide-In Ramps that can be conveniently stowed away when not in use. Come with a single piece bumper with light protection.
